HEPA Filter
AstroCel® II HEPA Filter
High-performance protection for critical environments. Provides savings on overall operating costs by using the lowest-resistance fiberglass laminar flow HEPA/ULPA media on the market.
Description
AstroCel® II HEPA Filter
LOW PRESSURE DROP MINI-PLEAT HEPA/ULPA FILTER
Product Overview
- Individually tested for certified performance
- Reduces operating costs with lowest possible pressure drop from microglass media
- Gasket seal, gel seal and knife edge designs available
- Available with media ribbon or hot melt separators
- Available in a range of efficiencies
- Lightweight and compact
Energy Saving Design
AAF Flanders’ mini-pleat AstroCel II filters are ideal for demanding operating conditions in critical applications. A longer service life and lower energy consumption means fewer change-outs and lower operating costs.
Unique construction
Astrocel II filters are available with media ribbon or hot melt separators to meet the requirements of all mini-pleat applications. Pack depths are available between 2“– 4” to optimize energy savings by minimizing total ownership costs.
Range of Efficiencies
Efficiencies from 99.99% on 0.3 micrometer to 99.9995% on 0.1 – 0.2 micrometer particles. Custom efficiencies are available.
Media Type
Fiberglass
Frame Material
Aluminum Extrusion
Max Operating Temperature
158˚F (70˚C)
