Ceiling | Surface Mounted
Opal LED Oyster
Opal Body
CCT | Dimmable Options
Apartments | Commercial Spaces
| 29605 |
Description
OPAL LED Oyster
LED Oyster SO3700/TC/DP 8 to 30 watt with selectable colour temperature and dual power
A perfect choice for apartments or commercial spaces
Select colour temperature with DIP switch 3000K / 4000K / 6000K
Durable powder coated steel body profile with a high performance opal PMMA diffuser
High efficiency SMD LED chips, CRI > 80
Integral constant current non-dimmable LED driver
Integral dual power selection for DP models
Two versatile profile sizes 8/16 or 15/30 watt, Microwave sensor option (SO3700/40L/TC/DP), corridor
STANDBY options available
8W/16W
Max Values Shown 3000K-1160lm | 4000K-1260lm | 6000K-1200lm | CRI 80 | Beam Angle 120° | Body Colour White | Diameter 310mm | Height 100mm (H)
15W/30W
Max Values Shown 3000K-2450lm | 4000K-2680lm | 6000K-2550 | CRI 80 | Beam Angle 120° | Body Colour White | Diameter 390mm | Height 112mm (H)
Optional Dimming Controls
Dimmer Type - Trailing edge, 1-10V, DALI / DSI (SO3700/40L/TC/DP)
