Ceiling Fan AC
Intercept 2
Maximum Airflow 11,911m³/hr
No Light | E27 Light | LED Light
Suitable for all rooms in the home environment
| 20333 |
Description
Introducing the three versions of the Intercept Family.
No Light | E27 Light | LED Light
Introduced in 2009 Intercept 2 quickly became a best seller thanks to its blend of style, reliability and performance.
Based on the class leading Concept family Intercept has excellent airflow and robust plywood blades.
Ceiling fans circulate air within a room and provide a cooling effect through the action of air moving over the skin.
In addition to making the room feel up to 6° cooler, they can significantly assist in savings up to 30% off your energy bills.
In winter ceiling fans redistribute warm air that gathers at the ceiling.
Running your fans in reverse, draws the air that naturally rises and gently re-circulating it throughout the room. Therefore balance the room’s temperature.
All ceiling fans should be at least 2.1 meters from floor to tip of the blades and at least 300mm from ceiling.
AC vs DC FANS
Alternating Current Motors (AC) use supplied power directly and regulate speeds by controlling frequency. AC Motors generally only have 3 speeds.
Direct Current motors (DC) convert supplied power directly. and regulate speeds by controlling electrical current. These Motors use up to 70% less energy than standard AC fans. Furthermore DC Ceiling Fans are more efficient, offering virtually silent operation.
Direct Current models usually have 5 or 6 speeds and are remote controlled.
Ceiling Fans purchased through Davis + Spence are covered by a Manufacturer’s Warranty
Always use a licenced professional for installation.
| 20333 |
•
3 Speed Wall control supplied
•
Timber Blades
•
Die cast aluminium body
•
2 years 'in-home' warranty on non-user replaceable parts. 5 years warranty on user replaceable parts
•
18w to 55w LED or E27 integrated Light
•
1320 (52") diameter
Installation Manual
Motor
16 Pole, 153mm x 18mm motor Made with high grade copper windings and silicone steel stator. Bearings are sealed to ensure quiet operation and long life.
Motor Housing
Materials: Die Cast Aluminium
Available Motor Housing Colours
White, Brushed Aluminium and Matt Black
Blades
1320mm (52”) Materials: Plywood Timber Blades Blade Pitch: 12°
Available Blade Colours
White, Silver and Matt Black
Extra Information
3 Speed wall controller | Reversible
Standard Canopy Cover
Suitable for flat and pitched ceilings up to 28°
Wall Controller Speed Capacitor Values
3.5µF & 2µF
Accessories (Supplied separately)
Remote Control Extension Down Rod 26mm diameter (includes wire harness) | 38° Ceiling Kit (for pitched ceilings) | T-Hook for ceiling roses
Warranty
3 years standard warranty “in home” 3 years extended warranty on motor only (excluding labour)
Light Fitting - option 1
E27 lamp holders (bulbs not supplied)
Light Fitting - option 2
LED Light: 24W CCT LED light (dimmable) | Colour temperatures: 3000K, 4000K and 6000K
