Ceiling Fan AC

Typhoon MACH 3 Stainless Steel 316

Added to List

Maximum Airflow 13,824 (48˝) |16,345 (52˝) |18,512 (56˝)

Three sizes 1220mm (48″) | 1320mm (52″) | 1420mm (56)

Light Adaptable (sold separately)

316 Stainless Steel

| 20333 |

Description

316 Stainless Steel is long lasting and characterises quality.

When installed outdoors and regularly maintained a 316 stainless steel fan will resist corrosion better than ordinary pressed steel fans.

Ceiling fans circulate air within a room and provide a cooling effect through the action of air moving over the skin.

In addition to making the room feel up to 6° cooler, they can significantly assist in savings up to 30% off your energy bills.

In winter ceiling fans redistribute warm air that gathers at the ceiling.

Running your fans in reverse, draws the air that naturally rises and gently re-circulating it throughout the room. Therefore balance the room’s temperature.

All ceiling fans should be at least 2.1 meters from floor to tip of the blades and at least 300mm from ceiling.

AC vs DC FANS

Alternating Current Motors  (AC) use supplied power directly and regulate speeds by controlling frequency. AC Motors generally only have 3 speeds.

Direct Current motors (DC) convert supplied power directly. and regulate speeds by controlling electrical current. These Motors use up to 70% less energy than standard AC fans. Furthermore DC Ceiling Fans are more efficient, offering virtually silent operation.

Direct Current models usually have 5 or 6 speeds and are remote controlled.

Ceiling Fans purchased through Davis + Spence are covered by a Manufacturer’s Warranty

Always use a licenced professional for installation.

| 20333 |

1220/1320/1420mm (48˝/52˝/56˝) 316 Stainless steel blades

Pressed 316 stainless steel body & canopy

Power usage: 14W to 64W (48˝)/15W to 68W (52˝)/18W to 72W (56˝)

Airflow: 13,824 (48˝)/ 16,345 (52˝)/18,512 (56˝)

Light adaptable (sold separately)

3 speed wall control (supplied)

Instruction Manual

Motor

16 Pole, 194 x 16mm Motor Made with the highest grade copper windings and silicone steel stator. Bearings are sealed to ensure quiet operation and long life.

Motor Housing

Materials: Pressed Steel (Painted, Plated or Powder Coated Finish)

Extra Information

3 Speed wall controller | Light Adaptable, Reversible.

Standard Canopy Cover

Suitable for flat and pitched ceilings up to 32°

Accessories (Supplied separately)

Remote Control | Extension Down Rod | Ceiling Kit (for pitched ceilings) | T-Hook for ceiling roses

Warranty

2 year standard “in home” warranty 3 years extended warranty on motor only (excluding labour)
